200MHz to 3GHz Double Ridged Broadband Waveguide Horn Antenna (Upgrade version of HA-02M03G-NF)
Frequency: 200MHz to 3GHz Gain: 3dbi to 12 dBi LxWxH: 986x960x720mm N.W.: 15 KG Connector: N-type Female - Max power: 600W Connector: 7/16-Female - Max power: 3000W (The connector can be adjusted by customer needs)
FT-RF specializes in producing:
- Military Antennas (Jammer Antenna, Military Horn antenna, Military vehicle antenna, Antenna Telescope Mast, Marine, Panel, Log Periodic antenna, Gooseneck, Whip, GPS, Connector, Adapter...) Please visit the website: https://military.ft-rf.com.tw/
- Outdoor Antenna and Indoor Antenna: Including Lora Antenna, ISM, LPWA antenna (868MHz antenna aka EU868, 915MHz antenna aka US915, 923MHz antenna aka AS923 and others.), 4G LTE antenna, 5G antenna, Wifi Antenna, Multi-Frequency Antenna, UHF antenna..., RF components, Cables and Connectors. We offer a variety of high-performance antennas for Global LoRaWAN applications, including 868 MHz, 915 MHz, 868 MHz, and 923 MHz... Our product line comprises both durable outdoor antennas and indoor high-performance dipole antennas that are suitable for a variety of LoRa applications, including Helium Network support. Please visit the website here: https://ft-rf.com.tw/.
- Horn Antenna: RF Microwave Antennas, EMC test equipment (Double Ridged Horn Antenna, Open boundary double ridged horn antenna, Quad Ridged Horn Antenna, Standard Gain Horn antenna, Waveguide to coax Adapter, precision Sleeve Dipole Antenna, Log Periodic Antenna, Antenna Tripod, RF connectors... Please visit the website: https://horn.ft-rf.com.tw/
We provide measurement and calibration Tests, ODM, OEM services for certain products.
We have hundreds of customers from over 60 countries, and to meet their demands, we developed a plant in Vietnam (with a total infrastructure area of 10000 square meters, which includes three major buildings dedicated to operations and production) in addition to the main manufacturing facility in Taiwan. Now, we are focusing on automatic production lines and investing in automation equipment. In the future, we pledge to deliver the highest-quality product in the shortest possible period.
雙脊喇叭天線
排序方式:Select
The horn antenna is a broadband passive device, shaped like a pyramid horn, referred to as a TEM antenna, which guides the beam of radio waves at a precise frequency. FT-RF Double Ridged Horn antennas have frequency capabilities ranging from 400MHz to 40GHz depending on type and style. These series are characterized by a huge frequency range and extremely high input powers. With increasing frequency, the gain rises to a maximum of 18 dBi. At higher frequencies, the increased gain compensates for the increasing cable losses.
The advantages of Horn antenna:
- Wide bandwidth: Because the horn antenna has no resonant parts, it can function over a wide range of frequencies.
- Easy waveguide interface: These antennas are very easy to interface to waveguide due to their shape, but they can also be designed with a transition so that a regular coaxial feeder can be used.
- Easy to make, simple design.
The horn is suitable for both transmitting and receiving purposes, especially suitable for EMC and immunity test measurements.
Recommended Accessories
- 天線三腳架: easy and fast-changing polarisation. 100% stable handling
- SMA Cable: High-quality special SMA cable
